GH-0402

swipe to see more

GH-0402 Series Electro-Optical Characteristics:

Code for parts GH-XXXXX	Lighting Color	Material	VF（V）		λ（nm）			lv（m cd）		Viewing angle at 50% lv	Lens color
			Typ	Max	λᴅ	λᴘ	△λ	Min	Typ
RV0402WS-DPJ		AlGalnP	2.0	2.5	630	640	18	50	110	150	White diff
YU0402WS-DPJ		AlGalnP	2.0	2.5	590	595	17	80	150	150	White diff

All information and data in this website are subject to change without prior notice.
