GH-2110

swipe to see more

GH-2110 Series Electro-Optical Characteristics:

Code for parts GH-XXXXX	Lighting Color	Material	VF（V）		λ（nm）			lv（m cd）		Viewing angle at 50% lv	Lens color
			Typ	Max	λᴅ	λᴘ	△λ	Min	Typ
MA2110TS-FSE		AlGalnP	2.0	2.5	635	645	20	40	80	150	Water transparent
		lnGaN	3.1	3.7	465	460	25	63	90	150
MA2110TS-JBJ		AlGalnP	2.0	2.5	640	655	19	50	85	150	Water transparent
		AlGalnP	2.0	2.5	590	595	17	100	170	150
MA2110TS-JlE		GaAsP	2.0	2.5	620	630	42	5	7	150	Water transparent
		GaP	2.0	2.5	570	565	31	8	18	150

All information and data in this website are subject to change without prior notice.
