GH-3195

swipe to see more

GH-3195 Series Electro-Optical Characteristics:

Code for parts GH-XXXXX	Lighting Color	Material	VF（V）		λ（nm）			lv（m cd）		Viewing angle at 50% lv	Lens color
			Typ	Max	λᴅ	λᴘ	△λ	Min	Typ
MP3195TS-CSE		AlGalnP	2.0	2.5	630	640	20	80	120	140	Water transparent
		AlGalnP	2.0	2.5	590	595	20	63	115	140
MP3195TS-HAH		AlGalnP	2.0	2.5	630	645	20	32	50	140	Water transparent
		lnGaN	3.3	3.7	470	465	25	50	75	140
WP3195TS-GQJ		AlGalnP	2.0	2.5	620	625	20	100	130	140	Water transparent
		lnGaN	3.1	3.7	520	515	43	125	220	140
		lnGaN	3.1	3.7	465	460	25	25	40	140

All information and data in this website are subject to change without prior notice.
