GH-S155

swipe to see more

GH-S155 Series Electro-Optical Characteristics:

Code for parts GH-XXXXX	Lighting Color	Material	VF（V）		λ（nm）			lv（m cd）		Viewing angle at 50% lv	Lens color
			Typ	Max	λᴅ	λᴘ	△λ	Min	Typ
MPS155TS-F4E		AlGalnP	2.0	2.5	630	640	18	50	110	140	Water transparent
		AlGalnP	2.0	2.5	570	575	18	32	60	140
MPS155TS-K2J		AlGalnP	2.0	2.5	623	630	18	80	150	140	Water transparent
		lnGaN	3.2	3.7	465	460	27	32	55	140
MPS155TS-KEJ		AlGalnP	2.0	2.5	640	650	18	40	55	140	Water transparent
		lnGaN	3.1	3.7	525	520	35	320	460	140
MPS155FS-JTJ		AlGalnP	2.0	2.5	605	610	17	80	160	140	Yellow
		lnGaN	3.1	3.7	x=0.22~0.38 Y=0.22~0.36			250	400	140

All information and data in this website are subject to change without prior notice.
